High power Monocrystalline equipment for manufacturer solar panels

MECHANICAL PARAMETERS

WORKING CONDITIONS

Dimensions(LxWxH)

1950x990x40

Maximum System voltage

DC1000(TUV)

Weight(kg)

17.4

Operating Temp

-45°C+80°C

Cable Length(mm)

900

Junction Box

IP65/IP67 Reted

Cable cross section size(mm²)

4

Static Loading

≤5400Pa

No.of cells and connections

72(12x6)

Maximum Serise Fuse(A)

15A

Frame

Anodized aluminum alloy

NOCT

47±2°C

Packing configuration

25/21pcs/carton

Application Class

Class A

ELECTRICAL PARAMETERS

Rated Maximum Power at STC(W)

250W

Maximum Power Voltage(Vmp/P)

7.78A

Maximum Power Current(Imp/A)

7.78A

Open Circuit Voltage(Voc/v)

8.2A

Short Circuit current(Isc/a)

8.2A

Power Tolerance

0 to +3%

Current Temperature Coefficient(Isc)

0.04%/°C

Voltage Temperature Coefficient(Voc)

-0.30%/°C

Power Temperature Coefficient(Pmp)

-0.39%/°C

GUARANTEE

5-year limited product warranty

Limited performance warranty:10 years at 90% of minimal rated power output, 25 years at 80% of the minimal rated power output
